Bathymetric contour data set 50m - 12,000m around the New Zealand region.Published Chart: CANZ Group (2008), ‘New Zealand Region Bathymetry’,1:4,000,000 scale at 46°S on Mercator projection, NIWA Chart, Miscellaneous Series No. 85, National Institute of Water and Atmospheric Research, Wellington, New ZealandGeographic Coverage: In the edgematching of this sheet with GEBCO sheet G.08, the bathymetry was taken from sheet G.08 for the following areas:24°-31°S,157°-158.5°E; 47°-54°S,157°-165°E; 54°-57.5°S,157°-163.5°E The bathymetry was compiled by NIWA at a scale of 1:1 million using a series of 18 separate Ocean Plotting Sheets on which the soundings were plotted. Each author (as listed above) worked on the interpretation and contouring of 3-4 sheets each and gravity data were used to assist in the interpretation. The resulting contours (at intervals of 250m) were then digitized and used in the production of the 1:4 million scale chart. The bathymetry was compiled from data held at:National Institute of Water and Atmosphere (NIWA) Hydrographic Office of the Royal New Zealand NavyUS National Geophysical Data Centre South Pacific Applied Geoscience Commission (Fiji);from published scientific papers; and from recent swath bathymetric surveys funded by Institut Francais de Recherche pour l’Exploitation de la Mer (IFREMER), France, NIWA and Seabed Mapping New Zealand Ltd.The shallow water contours (50m, 100m, 150m and 200m) were compiled from a database made up of the digitized contours from the NIWA coastal (1:200,000)chart series.

NIWA has published a lake chart for every lake in New Zealand that can be surveyed, except for Lake Dunstan. The charts are of various scales that are determined to be the most appropriate for the size of the lake. The compilation of bathymetry from echo-sounding surveys with publication dates ranging from 1966 to 1989. This dataset also contains newly surveyed bathymetry using multibeam information. New data as and when available shall be added to this dataset. Some of the lakes may have more than one set of bathymetry files. The earlier one could be from the period 1966 to 1989 and the new information from recent surveys undertaken for comparison purposes.

NIWA has published a lake chart for every lake in New Zealand that can be surveyed, except for Lake Dunstan. The charts are of various scales that are determined to be the most appropriate for the size of the lake. The compilation of bathymetry from echo-sounding surveys with publication dates ranging from 1966 to 1989. This dataset also contains newly surveyed bathymetry using multibeam information. New data as and when available shall be added to this dataset. Some of the lakes may have more than one set of bathymetry files. The earlier one could be from the period 1966 to 1989 and the new information from recent surveys undertaken for comparison purposes.

NIWA has published a lake chart for every lake in New Zealand that can be surveyed, except for Lake Dunstan. The charts are of various scales that are determined to be the most appropriate for the size of the lake. The compilation of bathymetry from echo-sounding surveys with publication dates ranging from 1966 to 1989. This dataset also contains newly surveyed bathymetry using multibeam information. New data as and when available shall be added to this dataset. Some of the lakes may have more than one set of bathymetry files. The earlier one could be from the period 1966 to 1989 and the new information from recent surveys undertaken for comparison purposes.

NIWA's bathymetry model of New Zealand at a 250m resolution. The 2016 model is a compilation of data digitised from published coastal charts, digital soundings archive, navy collector sheets and digital multibeam data sourced from surveys by NIWA, LINZ, as well as international surveys by vessels from United States of America, France, Germany, Australia, and Japan. All data used is held at NIWA.Image service can be used for analysis in ArcGIS Desktop or ArcGIS Online - no need to download the data, just stream using this service and classify, symbolise, mask, extract or apply map algebra - just like you would with local raster files. https://enterprise.arcgis.com/en/server/latest/publish-services/windows/key-concepts-for-image-services.htmMap information and metadata Offshore representation was generated from digital bathymetry at a grid resolution of 250m. Sun illumination is from an azimuth of 315° and 45° above the horizon.Projection Mercator 41 (WGS84 datum). EPSG: 3994Scale 1:5,000,000 at 41°S. Not to be used for navigational purposes Bibliographic reference Mitchell, J.S., Mackay, K.A., Neil, H.L., Mackay, E.J., Pallentin, A., Notman P., 2012. Undersea New Zealand, 1:5,000,000.  NIWA Chart, Miscellaneous Series No. 92Further Information: https://www.niwa.co.nz/our-science/oceans/bathymetry/further-informationLicence: https://www.niwa.co.nz/environmental-information/licences/niwa-open-data-licence-by-nn-nc-sa-version-1_________________________________________________________________________________________________________________Item Page Created: 2017-11-01 00:55 Item Page Last Modified: 2022-06-11 18:10Owner: NIWA_OpenData
